出口压力
|
进口压力
PSIG(Bar)
|
流量 SCFH(M3/H(N))
CAPACITIES IN SCFH(M3/H(N)) OF 0.8 SPECIFIC GRAVITY NATURAL GAS
|
|
阀体内部口径 Hes(Mm)
|
1/4 X3/8
(64x9.5)
|
1/2(12.7)
|
3/4(19.1)
|
7/8(22.2)
|
1-3/16(30.2)
|
1.0 To 3.25 Psig
(69 To 224 Mbar)
2 Psig
(138 Mbar)
±1%Psia(Bar)
T13593T0012
Light Blue
|
5(0.34)
10(0.69)
15(1.0)
20(1.4)
|
1020(27)
1550(42)
1920(51)
2240(60)
|
3640(98)
5610(156)
7580(203)
8960(240)
|
7440(199)
12040(323)
15990(429)
19250(516)
|
8850(232)
14410(386)
18950(508)
24110(646)
|
13560(363)
22570(605)
30760(824)
37410(1003)
|
25(1.7)
30(2.1)
40(2.8)
50(3.4)
60(4.1)
|
2570(69)
2890(77)
3530(95)
4180(112)
4820(129)
|
10250(275)
11540(309)
14120(378)
16700(448)
19280(517)
|
22030(590)
24800(665)
30350(813)
35890(962)
41440(1111)
|
27110(727)
31110(834)
38100(1021)
44100(1182)
51090(1369)
|
45330(1215)
51040(1368)
62450(1674)
73870(1980)
85290(2286)
|
80(5.5)
100(6.9)
125(8.6)
150(10.3)
175(12.1)
|
6110(164)
7400(198)
9020(242)
10630(285)
12240(328)
|
24440(655)
29600(793)
36050(966)
42500(1139)
48950(1312)
|
52540(1408)
63630(1705)
77500(2077)
91360(2448)
---------
|
65080(1744)
79060(2119)
96050(2574)
---------
---------
|
108120(2898)
----------
----------
----------
----------
|
3.2 To 6 Psig
(224 To 414 Mbar)
5 Psig
(345 Mbar)
±1%Psia(Bar)
T13671T0012
Orange
|
10(0.69)
15(1.0)
20(1.4)
25(1.7)
|
1390(37)
1870(50)
2240(60)
2570(69)
|
5050(135)
7280(195)
8850(237)
10250(275)
|
10350(277)
15150(406)
18640(500)
22030(590)
|
12900(340)
17950(481)
22970(616)
27110(727)
|
19030(510)
28530(765)
35820(960)
42530(1140)
|
30(2.1)
40(2.8)
50(3.4)
60(4.1)
80(5.5)
|
2890(77)
3530(95)
4180(112)
4820(129)
6110(164)
|
11540(309)
14120(378)
16700(448)
19280(517)
24440(655)
|
24800(665)
30350(813)
35890(952)
41440(1111)
52540(1408)
|
31110(834)
38100(1021)
44100(1182)
519090(1369)
65080(1744)
|
51040(1368)
62450(1674)
73870(1980)
85290(2286)
108120(2898)
|
100(6.9)
125(8.6)
150(10.3)
175(12.1)
|
7400(198)
9020(242)
10530(285)
12240(328)
|
29600(793)
36050(966)
42500(1139)
48950(1312)
|
63630(1705)
77500(2077)
91360(2448)
--------
|
79060(2119)
96050(2574)
---------
---------
|
----------
----------
----------
----------
|
6 To 16 Psig
(0.41 To 1.10 Bar)
10 Psig
(0.69 Bar)
±1%Psia(Bar)
T13600T0012
Red
|
15(1.0)
20(1.4)
25(1.7)
30(2.1)
|
1580(42)
2130(57)
2540(68)
2890(77)
|
5690(152)
8210(220)
9930(266)
11540(309)
|
11640(312)
17000(456)
20790(557)
24150(647)
|
12640(339)
20380(546)
24570(658)
29540(792)
|
21280(570)
31690(849)
39480(1058)
46550(1248)
|
40(2.8)
50(3.4)
60(4.1)
80(5.5)
|
3530(95)
4180(112)
4820(129)
6110(164)
|
14120(378)
16700(448)
19280(517)
24440(655)
|
30350(813)
35890(962)
41440(1111)
52540(1408)
|
38100(1021)
44100(1182)
51090(1369)
65080(1744)
|
62450(1674)
73870(1980)
85290(2266)
108120(2898)
|
100(6.9)
125(8.6)
150(10.3)
175(12.1)
|
7400(198)
9020(242)
10530(285)
12240(328)
|
29600(793)
36050(966)
42500(1139)
48950(1312)
|
63630(1705)
77500(2077)
91360(2448)
---------
|
79060(2119)
96050(2574)
---------
---------
|
---------
---------
---------
---------
|
